Cannondale SuperX 1 2026

Compare size-specific bike geometry, including reach, stack, angles, wheelbase and the measurements that influence fit and handling.

Cannondale › SuperX 1 › Standard › SuperX 1

SuperX 1 geometry measurements

Choose the recorded size and configuration. Geometry figures can change by size; RideDNA does not collapse those values into one misleading answer.

What is the reach of the Cannondale SuperX 1 2026?

Reach is the horizontal distance from the bottom bracket to the top of the head tube. Also searched as frame reach.

Configuration	Size	Reach	Source
SuperX 1 geometry	54	378 mm	Manufacturer-published
SuperX 1 geometry	46	365.3 mm	RideDNA-derived
SuperX 1 geometry	51	370.8 mm	RideDNA-derived
SuperX 1 geometry	58	392.1 mm	RideDNA-derived
SuperX 1 geometry	56	385.8 mm	RideDNA-derived
SuperX 1 geometry	61	397.9 mm	RideDNA-derived

What is the stack of the Cannondale SuperX 1 2026?

Stack is the vertical distance from the bottom bracket to the top of the head tube. Also searched as frame stack.

Configuration	Size	Stack	Source
SuperX 1 geometry	54	554.1 mm	RideDNA-derived
SuperX 1 geometry	46	514.9 mm	RideDNA-derived
SuperX 1 geometry	51	534.4 mm	RideDNA-derived
SuperX 1 geometry	58	594.7 mm	RideDNA-derived
SuperX 1 geometry	56	574 mm	RideDNA-derived
SuperX 1 geometry	61	614.5 mm	RideDNA-derived

What is the effective top tube of the Cannondale SuperX 1 2026?

Effective top tube is the horizontal distance between the head-tube and seat-tube centerlines. Also searched as ETT, virtual top tube, horizontal top tube.

Configuration	Size	Effective top tube	Source
SuperX 1 geometry	54	540 mm	Recorded geometry
SuperX 1 geometry	46	510 mm	Recorded geometry
SuperX 1 geometry	51	521 mm	Recorded geometry
SuperX 1 geometry	58	575 mm	Recorded geometry
SuperX 1 geometry	56	558 mm	Recorded geometry
SuperX 1 geometry	61	594 mm	Recorded geometry

What is the head tube angle of the Cannondale SuperX 1 2026?

Head tube angle describes the steering-axis angle relative to the ground. Also searched as HTA, head angle, steering angle.

Configuration	Size	Head tube angle	Source
SuperX 1 geometry	54	71 °	Recorded geometry
SuperX 1 geometry	46	70 °	Recorded geometry
SuperX 1 geometry	51	71 °	Recorded geometry
SuperX 1 geometry	58	71 °	Recorded geometry
SuperX 1 geometry	56	71 °	Recorded geometry
SuperX 1 geometry	61	71 °	Recorded geometry

What is the seat tube angle of the Cannondale SuperX 1 2026?

Seat tube angle describes the seat-tube angle relative to the ground. Also searched as STA, seat angle, effective seat angle.

Configuration	Size	Seat tube angle	Source
SuperX 1 geometry	54	73.7 °	Recorded geometry
SuperX 1 geometry	46	74.3 °	Recorded geometry
SuperX 1 geometry	51	74.3 °	Recorded geometry
SuperX 1 geometry	58	72.9 °	Recorded geometry
SuperX 1 geometry	56	73.3 °	Recorded geometry
SuperX 1 geometry	61	72.3 °	Recorded geometry

What is the trail of the Cannondale SuperX 1 2026?

Trail is the ground distance between the steering-axis intercept and the front tire contact point. Also searched as fork trail, mechanical trail.

Configuration	Size	Trail	Source
SuperX 1 geometry	54	62.7 mm	RideDNA-derived
SuperX 1 geometry	46	69.2 mm	RideDNA-derived
SuperX 1 geometry	51	62.7 mm	RideDNA-derived
SuperX 1 geometry	58	62.7 mm	RideDNA-derived
SuperX 1 geometry	56	62.7 mm	RideDNA-derived
SuperX 1 geometry	61	62.7 mm	RideDNA-derived

What is the wheelbase of the Cannondale SuperX 1 2026?

Wheelbase is the distance between the front and rear wheel axles. Also searched as axle-to-axle length.

Configuration	Size	Wheelbase	Source
SuperX 1 geometry	54	1019.5 mm	RideDNA-derived
SuperX 1 geometry	46	998.1 mm	RideDNA-derived
SuperX 1 geometry	51	1004 mm	RideDNA-derived
SuperX 1 geometry	58	1048.6 mm	RideDNA-derived
SuperX 1 geometry	56	1034.2 mm	RideDNA-derived
SuperX 1 geometry	61	1061.2 mm	RideDNA-derived

What is the chainstay length of the Cannondale SuperX 1 2026?

Chainstay length, also called rear center, is the distance from the bottom bracket to the rear axle. Also searched as Chainstay, rear center, rear centre.

Configuration	Size	Chainstay length	Source
SuperX 1 geometry	54	422 mm	Recorded geometry
SuperX 1 geometry	46	422 mm	Recorded geometry
SuperX 1 geometry	51	422 mm	Recorded geometry
SuperX 1 geometry	58	422 mm	Recorded geometry
SuperX 1 geometry	56	422 mm	Recorded geometry
SuperX 1 geometry	61	422 mm	Recorded geometry

What is the bottom bracket drop of the Cannondale SuperX 1 2026?

Bottom bracket drop is the vertical distance from the wheel-axle line down to the bottom bracket. Also searched as BB drop.

Configuration	Size	Bottom bracket drop	Source
SuperX 1 geometry	54	69 mm	Recorded geometry
SuperX 1 geometry	46	77 mm	Recorded geometry
SuperX 1 geometry	51	72 mm	Recorded geometry
SuperX 1 geometry	58	67 mm	Recorded geometry
SuperX 1 geometry	56	69 mm	Recorded geometry
SuperX 1 geometry	61	67 mm	Recorded geometry

What is the bottom bracket height of the Cannondale SuperX 1 2026?

Bottom bracket height is the vertical distance from the ground to the bottom bracket. Also searched as BB height.

Configuration	Size	Bottom bracket height	Source
SuperX 1 geometry	54	282 mm	RideDNA-derived
SuperX 1 geometry	46	274 mm	RideDNA-derived
SuperX 1 geometry	51	279 mm	RideDNA-derived
SuperX 1 geometry	58	284 mm	RideDNA-derived
SuperX 1 geometry	56	282 mm	RideDNA-derived
SuperX 1 geometry	61	284 mm	RideDNA-derived

What is the front center of the Cannondale SuperX 1 2026?

Front center is the distance from the bottom bracket to the front wheel axle. Also searched as front centre.

Configuration	Size	Front center	Source
SuperX 1 geometry	54	607.1 mm	RideDNA-derived
SuperX 1 geometry	46	588.2 mm	RideDNA-derived
SuperX 1 geometry	51	592.6 mm	RideDNA-derived
SuperX 1 geometry	58	635.5 mm	RideDNA-derived
SuperX 1 geometry	56	621.7 mm	RideDNA-derived
SuperX 1 geometry	61	648 mm	Manufacturer-published

What is the fork offset of the Cannondale SuperX 1 2026?

Fork offset is the perpendicular distance between the steering axis and the front axle. Also searched as fork rake, rake.

Configuration	Size	Fork offset	Source
SuperX 1 geometry	54	55 mm	Manufacturer-published
SuperX 1 geometry	46	55 mm	Manufacturer-published
SuperX 1 geometry	51	55 mm	Manufacturer-published
SuperX 1 geometry	58	55 mm	Manufacturer-published
SuperX 1 geometry	56	55 mm	Manufacturer-published
SuperX 1 geometry	61	55 mm	Manufacturer-published

What is the head tube length of the Cannondale SuperX 1 2026?

Head tube length is the measured length of the frame's head tube. Also searched as Head tube, head tube.

Configuration	Size	Head tube length	Source
SuperX 1 geometry	54	132 mm	Recorded geometry
SuperX 1 geometry	46	86 mm	Recorded geometry
SuperX 1 geometry	51	108 mm	Recorded geometry
SuperX 1 geometry	58	177 mm	Recorded geometry
SuperX 1 geometry	56	153 mm	Recorded geometry
SuperX 1 geometry	61	198 mm	Recorded geometry

What is the seat tube length of the Cannondale SuperX 1 2026?

Seat tube length is the recorded length of the frame's seat tube; measurement conventions can differ by manufacturer. Also searched as Seat tube, seat tube, frame size.

Configuration	Size	Seat tube length	Source
SuperX 1 geometry	54	524 mm	Recorded geometry
SuperX 1 geometry	46	449 mm	Recorded geometry
SuperX 1 geometry	51	488 mm	Recorded geometry
SuperX 1 geometry	58	566 mm	Recorded geometry
SuperX 1 geometry	56	546 mm	Recorded geometry
SuperX 1 geometry	61	589 mm	Recorded geometry

What is the standover height of the Cannondale SuperX 1 2026?

Standover height is the ground-to-top-tube height at the manufacturer's stated measurement point. Also searched as Standover, stand over height, standover clearance.

Configuration	Size	Standover height	Source
SuperX 1 geometry	54	784.1 mm	RideDNA-derived
SuperX 1 geometry	46	721.1 mm	RideDNA-derived
SuperX 1 geometry	51	754.6 mm	RideDNA-derived
SuperX 1 geometry	58	825.5 mm	RideDNA-derived
SuperX 1 geometry	56	804.1 mm	RideDNA-derived
SuperX 1 geometry	61	845.6 mm	RideDNA-derived

What is the fork length of the Cannondale SuperX 1 2026?

Fork length is the axle-to-crown distance recorded for the fork. Also searched as axle to crown, A2C.

Configuration	Size	Fork length	Source
SuperX 1 geometry	54	400 mm	Manufacturer-published
SuperX 1 geometry	46	400 mm	Manufacturer-published
SuperX 1 geometry	51	400 mm	Manufacturer-published
SuperX 1 geometry	58	400 mm	Manufacturer-published
SuperX 1 geometry	56	400 mm	Manufacturer-published
SuperX 1 geometry	61	400 mm	Manufacturer-published

What is the wheel flop of the Cannondale SuperX 1 2026?

Wheel flop is a calculated steering-geometry value based on trail and head tube angle. Also searched as flop.

Configuration	Size	Wheel flop	Source
SuperX 1 geometry	54	19.3 mm	RideDNA-derived
SuperX 1 geometry	46	22.2 mm	RideDNA-derived
SuperX 1 geometry	51	19.3 mm	RideDNA-derived
SuperX 1 geometry	58	19.3 mm	RideDNA-derived
SuperX 1 geometry	56	19.3 mm	RideDNA-derived
SuperX 1 geometry	61	19.3 mm	RideDNA-derived

Geometry

Available sizes: 54, 46, 51, 58, 56, 61.

SuperX 1 geometry

Jump to size: 46 · 51 · 54 · 56 · 58 · 61

SuperX 1 geometry geometry by size
Size	Reach	Stack	ETT	HTA	STA	Trail	Wheelbase	Chainstay	BB drop	BB height	Front center	Fork offset	Head tube	Seat tube	Standover	Fork length	Wheel flop	Max tire
46	365.3 mm^*	514.9 mm^*	510 mm^‡	70 °^‡	74.3 °^‡	69.2 mm^*	998.1 mm^*	422 mm^‡	77 mm^‡†	274 mm^*†	588.2 mm^*	55 mm	86 mm^‡	449 mm^‡	721.1 mm^*	400 mm	22.2 mm^*†	†
51	370.8 mm^*	534.4 mm^*	521 mm^‡	71 °^‡	74.3 °^‡	62.7 mm^*	1004 mm^*	422 mm^‡	72 mm^‡†	279 mm^*†	592.6 mm^*	55 mm	108 mm^‡	488 mm^‡	754.6 mm^*	400 mm	19.3 mm^*†	†
54	378 mm	554.1 mm^*	540 mm^‡	71 °^‡	73.7 °^‡	62.7 mm^*	1019.5 mm^*	422 mm^‡	69 mm^‡†	282 mm^*†	607.1 mm^*	55 mm	132 mm^‡	524 mm^‡	784.1 mm^*	400 mm	19.3 mm^*†	†
56	385.8 mm^*	574 mm^*	558 mm^‡	71 °^‡	73.3 °^‡	62.7 mm^*	1034.2 mm^*	422 mm^‡	69 mm^‡†	282 mm^*†	621.7 mm^*	55 mm	153 mm^‡	546 mm^‡	804.1 mm^*	400 mm	19.3 mm^*†	†
58	392.1 mm^*	594.7 mm^*	575 mm^‡	71 °^‡	72.9 °^‡	62.7 mm^*	1048.6 mm^*	422 mm^‡	67 mm^‡†	284 mm^*†	635.5 mm^*	55 mm	177 mm^‡	566 mm^‡	825.5 mm^*	400 mm	19.3 mm^*†	†
61	397.9 mm^*	614.5 mm^*	594 mm^‡	71 °^‡	72.3 °^‡	62.7 mm^*	1061.2 mm^*	422 mm^‡	67 mm^‡†	284 mm^*†	648 mm	55 mm	198 mm^‡	589 mm^‡	845.6 mm^*	400 mm	19.3 mm^*†	†

Length measurements are in millimeters; HTA and STA are in degrees. ETT means effective top tube. Values prioritize RideDNA calculations. * RideDNA calculated (including corrections where published values differ). Unmarked values are manufacturer-published; matching independently calculated values are identified in their source notes. † Manufacturer did not publish this dimension; † alone means no reliable value is available. ‡ Staff reference or source not confirmed; see the source note. Open Geometry Audit for the original published values, calculated geometry, and deltas.

Size-to-size changes

Differences are calculated from the recorded values; they are not fit recommendations.

SuperX 1 geometry: 46 → 51 — Reach +5.5 mm, Stack +19.5 mm, ETT +11 mm, HTA +1 °, STA +0 °, Trail -6.5 mm, Wheelbase +5.9 mm, Chainstay +0 mm, BB drop -5 mm, BB height +5 mm, Front center +4.4 mm, Fork offset +0 mm, Head tube +22 mm, Seat tube +39 mm, Standover +33.5 mm, Fork length +0 mm, Wheel flop -2.9 mm
SuperX 1 geometry: 51 → 54 — Reach +7.2 mm, Stack +19.7 mm, ETT +19 mm, HTA +0 °, STA -0.6 °, Trail +0 mm, Wheelbase +15.5 mm, Chainstay +0 mm, BB drop -3 mm, BB height +3 mm, Front center +14.5 mm, Fork offset +0 mm, Head tube +24 mm, Seat tube +36 mm, Standover +29.5 mm, Fork length +0 mm, Wheel flop +0 mm
SuperX 1 geometry: 54 → 56 — Reach +7.8 mm, Stack +19.9 mm, ETT +18 mm, HTA +0 °, STA -0.4 °, Trail +0 mm, Wheelbase +14.7 mm, Chainstay +0 mm, BB drop +0 mm, BB height +0 mm, Front center +14.6 mm, Fork offset +0 mm, Head tube +21 mm, Seat tube +22 mm, Standover +20 mm, Fork length +0 mm, Wheel flop +0 mm
SuperX 1 geometry: 56 → 58 — Reach +6.3 mm, Stack +20.7 mm, ETT +17 mm, HTA +0 °, STA -0.4 °, Trail +0 mm, Wheelbase +14.4 mm, Chainstay +0 mm, BB drop -2 mm, BB height +2 mm, Front center +13.8 mm, Fork offset +0 mm, Head tube +24 mm, Seat tube +20 mm, Standover +21.4 mm, Fork length +0 mm, Wheel flop +0 mm
SuperX 1 geometry: 58 → 61 — Reach +5.8 mm, Stack +19.8 mm, ETT +19 mm, HTA +0 °, STA -0.6 °, Trail +0 mm, Wheelbase +12.6 mm, Chainstay +0 mm, BB drop +0 mm, BB height +0 mm, Front center +12.5 mm, Fork offset +0 mm, Head tube +21 mm, Seat tube +23 mm, Standover +20.1 mm, Fork length +0 mm, Wheel flop +0 mm

RideDNA-derived values

These deterministic calculations use the recorded inputs above. They are separate from recorded facts and are not fit recommendations.

SuperX 1 geometry size 54 stack Reach Ratio: 1.47
SuperX 1 geometry size 46 stack Reach Ratio: 1.41
SuperX 1 geometry size 51 stack Reach Ratio: 1.44
SuperX 1 geometry size 58 stack Reach Ratio: 1.52
SuperX 1 geometry size 56 stack Reach Ratio: 1.49
SuperX 1 geometry size 61 stack Reach Ratio: 1.54
