Gravel bikes — geometry survey

Gravel bikes split the difference between road race fits and XC stability. Expect slacker head angles than road, longer wheelbases, and longer chainstays for loaded riding and loose surfaces.

Every Gravel bike in the catalog

Bike	Stack	Reach	HTA	Trail	WB	CS
Pinarello Dogma GR 2026	566 mm	384 mm	71.0 °	68.0 mm	1026 mm	425 mm
Specialized Diverge 2025	555 mm	406 mm	71.0 °	65.0 mm	1048 mm	430 mm
Cannondale SuperX 2026	564 mm	382 mm	71.0 °	65.0 mm	1027 mm	422 mm
Factor Aluto 2026	575 mm	398 mm	72.0 °	61.2 mm	1025 mm	422 mm
Pinarello Grevil F 2026	580 mm	393 mm	71.3 °	65.4 mm	1048 mm	430 mm
Cannondale Topstone Carbon 2026	588 mm	380 mm	70.7 °	67.0 mm	1031 mm	420 mm
ENVE MOG 2026	576 mm	393 mm	71.3 °	66.0 mm	1035 mm	420 mm
3T Ultra 700c 2026	574 mm	387 mm	71.5 °	62.5 mm	1020 mm	419 mm
Canyon Grail 2026	590 mm	411 mm	71.5 °	63.3 mm	1057 mm	425 mm
Salsa Cutthroat C 2026	621 mm	385 mm	69.0 °	87.4 mm	1091 mm	445 mm
Lauf Seigla 2026	565 mm	388 mm	70.5 °	78.0 mm	1035 mm	425 mm
Litespeed ULTIMATE G2 2026	571 mm	392 mm	71.5 °	68.1 mm	1031 mm	425 mm
Moots Routt RSL 2026	577 mm	384 mm	70.5 °	78.0 mm	1045 mm	437 mm
Niner ORE 9 RDO 2026	588 mm	409 mm	69.0 °	81.2 mm	1091 mm	435 mm
Niner RLT 9 RDO 2026	585 mm	379 mm	71.3 °	73.3 mm	1024 mm	430 mm
Pinarello Granger 2026	581 mm	387 mm	70.6 °	72.1 mm	1041 mm	430 mm
Pivot Vault (Rigid) 2026	579 mm	398 mm	70.6 °	68.5 mm	1044 mm	420 mm
Cervelo R5-CX 2026	550 mm	386 mm	71.5 °	58.7 mm	1023 mm	425 mm
Orbea Terra 2026	591 mm	398 mm	70.3 °	81.8 mm	1051 mm	430 mm
Trek Checkpoint 2026	590 mm	395 mm	71.8 °	66.0 mm	1039 mm	430 mm
Cervelo Aspero 2026	568 mm	393 mm	72.0 °	62.0 mm	1019 mm	425 mm
Wilier Rave 2026	570 mm	391 mm	71.0 °	72.2 mm	1029 mm	421 mm
Ridley ASTR RS 2026	571 mm	406 mm	71.5 °	68.7 mm	1043 mm	425 mm
Santa Cruz Stigmata 2026	588 mm	412 mm	69.5 °	85.0 mm	1075 mm	430 mm
Trek Checkout 2026	634 mm	414 mm	69.4 °	88.0 mm	1111 mm	442 mm
Allied Able 2026	565 mm	397 mm	70.5 °	67.7 mm	1055 mm	435 mm
BMC Kaius 2026	561 mm	402 mm	72.0 °	68.0 mm	1020 mm	420 mm
Scott Scale Gravel RC 2026	609 mm	454 mm	67.9 °	105.0 mm	1144 mm	425 mm
BMC URS 2026	580 mm	410 mm	69.5 °	86.0 mm	1070 mm	430 mm
Cervelo Aspero-5 2026	562 mm	389 mm	71.6 °	63.2 mm	1019 mm	423 mm
3T Racemax 2 Italia 2026	579 mm	379 mm	71.5 °	61.5 mm	1016 mm	420 mm
Salsa Flyway C 2026	580 mm	399 mm	70.5 °	70.9 mm	1049 mm	425 mm
Canyon Grizl CF 2026	596 mm	405 mm	71.0 °	66.5 mm	1077 mm	440 mm
Parlee Taos 2026	595 mm	396 mm	69.5 °	86.9 mm	1059 mm	430 mm
Specialized Crux 2026	569 mm	393 mm	71.8 °	65.5 mm	1028 mm	425 mm
Scott Addict Gravel RC 2026	565 mm	387 mm	71.0 °	64.5 mm	1029 mm	425 mm
3T Extrema Italia 2026	580 mm	382 mm	71.0 °	62.8 mm	1049 mm	437 mm
Airborne Endeavor 2026	—	—	—	—	—	—
Airborne Marauder 2026	—	—	—	—	—	—
Airborne Arsenal 7° 2026	—	—	—	—	—	—

What the numbers say about Gravel geometry

The Gravel cohort in this audit covers 40 bikes from 24 brands and a single fit styles. That sample is large enough to draw aggregate conclusions about how the segment is currently being designed, while still small enough that individual outliers stand out.

Stack across this cohort runs 550 mm – 634 mm (mean 579 mm). Reach runs 379 mm – 454 mm (mean 396 mm). Head-tube angles cluster between 67.9 ° – 72.0 ° (mean 70.8 °), which is the single strongest fingerprint of the discipline — a frame outside this band is almost certainly being marketed into a different category. Mechanical trail spans 58.7 mm – 105.0 mm (mean 71.4 mm), wheelbase spans 1016 mm – 1144 mm (mean 1047 mm), and chainstay length spans 419 mm – 445 mm (mean 428 mm).

The tightest-handling bike in the set on pure wheelbase is the 3T Racemax 2 Italia 2026; the most stable is the Scott Scale Gravel RC 2026. Wheelbase alone is a noisy proxy for handling — front-centre, rear-centre, and trail all matter — but it is the cleanest single number for "how big does the bike feel between the wheels", and the spread above tells you that Gravel as a category has not converged on one answer.

If you are shopping by fit, start from the cohort table at the top of this page, sort visually by stack and reach, and then pivot to side-by-side comparisons on the comparison tool. If you are shopping by handling, the trail and wheelbase leaderboards rank the same data on a single axis at a time. And if you already have a bike you like, the "bikes like…" pages will surface the closest geometric matches across the entire catalog, not just within one discipline.

One caveat worth remembering: published geometry is the static, un-loaded frame. The way a Gravel bike actually rides also depends on tyre choice, fork sag (for any suspended models), and bar/stem stack. The numbers above are the foundation, not the whole story — but they are the foundation that every other variable sits on top of.
