Ranked by Euclidean distance across stack, reach, head-tube angle, mechanical trail, chainstay length, wheelbase, and bottom-bracket drop — all z-scaled so no metric dominates.
| Stack | 565 mm | Reach | 397 mm |
|---|---|---|---|
| Head-tube angle | 70.5 ° | Trail | 67.7 mm |
| Chainstay | 435 mm | Wheelbase | 1055 mm |
| BB drop | 80 mm | Type | Gravel |
| # | Bike | Δ | Stack | Reach | HTA | Trail | WB |
|---|---|---|---|---|---|---|---|
| 1 | Specialized Diverge 2025 | 1.67 | 555 mm | 406 mm | 71.0 ° | 65.0 mm | 1048 mm |
| 2 | 3T Extrema Italia 2026 | 1.79 | 580 mm | 382 mm | 71.0 ° | 62.8 mm | 1049 mm |
| 3 | Salsa Flyway C 2026 | 1.99 | 580 mm | 399 mm | 70.5 ° | 70.9 mm | 1049 mm |
| 4 | Orbea Terra 2026 | 2.24 | 591 mm | 398 mm | 70.3 ° | 81.8 mm | 1051 mm |
| 5 | Pinarello Granger 2026 | 2.28 | 581 mm | 387 mm | 70.6 ° | 72.1 mm | 1041 mm |
| 6 | Ridley ASTR RS 2026 | 2.29 | 571 mm | 406 mm | 71.5 ° | 68.7 mm | 1043 mm |
| 7 | Trek Checkpoint 2026 | 2.39 | 590 mm | 395 mm | 71.8 ° | 66.0 mm | 1039 mm |
| 8 | Canyon Grizl CF 2026 | 2.49 | 596 mm | 405 mm | 71.0 ° | 66.5 mm | 1077 mm |
Across the 8 closest matches in the catalog the Allied Able 2026 fits a recognisable cluster of Gravel bikes. The neighbour set was selected only from the same bike-type bucket and only from models for which we have a full stack/reach/HTA/trail/chainstay/wheelbase/BB-drop record — so the distance numbers above are like-for-like, not apples-to-oranges.
The single closest geometric match is the Specialized Diverge 2025, with a normalised distance of 9.6 mm of stack and 9.3 mm of reach separating the two. Riders who liked the position of one will almost always feel at home on the other.
Allied Able 2026 runs about 15.6 mm less stack than the median of its closest neighbours, so this is the more aggressive pick of the cluster — better for race fits, lower bar drops, and riders who want their stem closer to the steerer-tube cap.
The Allied Able 2026 sits almost exactly on the reach mean for this peer set, which is a strong signal that the brand built it to a familiar template rather than chasing a niche fit.
The Allied Able 2026 sits almost exactly on the trail mean for this peer set, which is a strong signal that the brand built it to a familiar template rather than chasing a niche fit.
Use the side-by-side comparison links below to drill in on any specific pairing. Every comparison page on RideDNA is computed from the same audited geometry tables that power this list, so the numbers will be internally consistent. If you'd rather start from your existing fit, the Fit Wizard takes a few of your current bike's measurements and re-runs this same nearest-neighbour search from your seat, not from a brand the manufacturer chose to compete with.
Method. Each of the seven metrics is z-scaled by its standard deviation across the candidate pool before being summed in the Euclidean norm. This avoids wheelbase (typically ±50 mm of variation) drowning out HTA (±2° of variation). We deliberately do not include subjective scores in this similarity calculation — the goal is geometric kinship, not handling kinship. Two bikes that share geometry but pair it with very different fork offsets or tyre clearances can still feel different on the trail; the Handling Index page is the better tool for that question.
