Ranked by Euclidean distance across stack, reach, head-tube angle, mechanical trail, chainstay length, wheelbase, and bottom-bracket drop — all z-scaled so no metric dominates.
| Stack | 581 mm | Reach | 387 mm |
|---|---|---|---|
| Head-tube angle | 70.6 ° | Trail | 72.1 mm |
| Chainstay | 430 mm | Wheelbase | 1041 mm |
| BB drop | 72 mm | Type | Gravel |
| # | Bike | Δ | Stack | Reach | HTA | Trail | WB |
|---|---|---|---|---|---|---|---|
| 1 | Niner RLT 9 RDO 2026 | 1.08 | 585 mm | 379 mm | 71.3 ° | 73.3 mm | 1024 mm |
| 2 | Pinarello Dogma GR 2026 | 1.41 | 566 mm | 384 mm | 71.0 ° | 68.0 mm | 1026 mm |
| 3 | Moots Routt RSL 2026 | 1.41 | 577 mm | 384 mm | 70.5 ° | 78.0 mm | 1045 mm |
| 4 | Salsa Flyway C 2026 | 1.45 | 580 mm | 399 mm | 70.5 ° | 70.9 mm | 1049 mm |
| 5 | Pinarello Grevil F 2026 | 1.47 | 580 mm | 393 mm | 71.3 ° | 65.4 mm | 1048 mm |
| 6 | Litespeed ULTIMATE G2 2026 | 1.50 | 571 mm | 392 mm | 71.5 ° | 68.1 mm | 1031 mm |
| 7 | Scott Addict Gravel RC 2026 | 1.55 | 565 mm | 387 mm | 71.0 ° | 64.5 mm | 1029 mm |
| 8 | 3T Extrema Italia 2026 | 1.72 | 580 mm | 382 mm | 71.0 ° | 62.8 mm | 1049 mm |
Across the 8 closest matches in the catalog the Pinarello Granger 2026 fits a recognisable cluster of Gravel bikes. The neighbour set was selected only from the same bike-type bucket and only from models for which we have a full stack/reach/HTA/trail/chainstay/wheelbase/BB-drop record — so the distance numbers above are like-for-like, not apples-to-oranges.
The single closest geometric match is the Niner RLT 9 RDO 2026, with a normalised distance of 3.4 mm of stack and 7.7 mm of reach separating the two. Riders who liked the position of one will almost always feel at home on the other.
Pinarello Granger 2026 runs about 5.9 mm more stack than the median of its closest neighbours, so this is the more upright pick of the cluster — better for endurance fits, riders with limited hip flexion, and anyone who wants the bars high without an enormous spacer stack.
The Pinarello Granger 2026 sits almost exactly on the reach mean for this peer set, which is a strong signal that the brand built it to a familiar template rather than chasing a niche fit.
Pinarello Granger 2026 runs about 3.2 mm more trail than the median of its closest neighbours, so the steering is calmer and more self-centring than its peers — better for descents, loaded riding, and high-speed gravel.
Use the side-by-side comparison links below to drill in on any specific pairing. Every comparison page on RideDNA is computed from the same audited geometry tables that power this list, so the numbers will be internally consistent. If you'd rather start from your existing fit, the Fit Wizard takes a few of your current bike's measurements and re-runs this same nearest-neighbour search from your seat, not from a brand the manufacturer chose to compete with.
Method. Each of the seven metrics is z-scaled by its standard deviation across the candidate pool before being summed in the Euclidean norm. This avoids wheelbase (typically ±50 mm of variation) drowning out HTA (±2° of variation). We deliberately do not include subjective scores in this similarity calculation — the goal is geometric kinship, not handling kinship. Two bikes that share geometry but pair it with very different fork offsets or tyre clearances can still feel different on the trail; the Handling Index page is the better tool for that question.
